| 700C Rims O.W.30mm Tubeless Ready | |||||||||
|---|---|---|---|---|---|---|---|---|---|
 |  |  |  |  | |||||
| Model | ULV217 | Model | ULV182 | Model | ULV161 | Model | ULV183 | Model | ULV168 |
| ERD | 574mm | ERD | 552mm | ERD | 544mm | ERD | 524mm | ERD | 468mm |
| OD | 633mm | OD | 633mm | OD | 633mm | OD | 633mm | OD | 633mm |
| Depth | 35mm | Depth | 46mm | Depth | 50mm | Depth | 60mm | Depth | 88mm |
| Regular | 432±15g | Regular | 465±15g | Regular | 480±15g | Regular | 480±15g | Regular | 520±15g |
| Light | 390±15g | Light | 415±15g | Light | 435±15g | Light | 425±15g | Light | 470±15g |
Use for: All Road, Gravel
Type:Clincher–Tubeless ready
Material: Toray T700S/T800 carbon
Holes: 16H ~ 36H
Finish: Matte/ Glossy
Weave: UD/ 3K/ 3K Twill/ 12K/ 12K Twill
Assembly Hole Dia: Ø 7.5mm
Spokes Hole Dia: Ø 4.5mm
Valve Hole Dia: Ø 6.5mm
Max Rider Weight: 130kgs/285lbs
Max Spoke Tension Tested: >300kgf
Max Tyre Pressure Tested: 125psi/8.6bar
Flatness: <0.15mm
Roundess: <0.2mm
Ultimate Strength: >100kgs
Torsion Strength: >50kgs
Dynamic Equilibrium: <3g
Standard: Base and exceed EN ISO 4210
FAQ
Q: What tire width fits this 30mm all road carbon rim?
A: It supports wider gravel & all-road tires for mixed pavement and rough roads.
Q: What benefits does the 30mm rim width bring?
A: Larger tire contact area, better grip and more stable riding on uneven surfaces.
Q: Can we customize logos and spoke holes?
A: Custom decals and spoke hole options available for bulk OEM orders.
